Product Summary

The XCR3064XL-7CS48I is a CoolRunner XPLA3 CPLD. The XCR3064XL-7CS48I CPLD is targeted for low power systems that include portable, handheld, and power sensitive applications. Each member of the CoolRunner XCR3064XL-7CS48I includes Fast Zero Power (FZP) design technology that combines low power and high speed. With this design technique, the CoolRunner XCR3064XL-7CS48I offers true pin-to-pin speeds of 5.0 ns, while simultaneously delivering power that is less than 56 μW at standby without the need for turbo bits or other power down schemes.

Parametrics

XCR3064XL-7CS48I absolute maximum ratings: (1)VCC Supply voltage(2) relative to GND: –0.5 4.0 V; (2)VI Input voltage(3) relative to GND: –0.5 5.5(4) V; (3)IOUT Output current, per pin: –100 100 mA; (4)TJ Maximum junction temperature: –40 150 ℃; (5)TSTR Storage temperature: –65 150 ℃.

Features

XCR3064XL-7CS48I features: (1)Fast Zero Power (FZP) design technique provides ultra-low power and very high speed; (2)Typical Standby Current of 17 to 18μA at 25℃; (3)Innovative CoolRunnerXPLA3 architecture combines high speed with extreme flexibility; (4)Based on industrys first TotalCMOS PLD both CMOS design and process technologies; (5)Advanced 0.35five layer metal EEPROM process; (6)1,000 erase/program cycles guaranteed; (7)20 years data retention guaranteed; (8)3V, In-System Programmable (ISP) using JTAG IEEE 1149.1 interface.

Diagrams

XCR3064XL-7CS48I Architecture

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
XCR3064XL-7CS48I
XCR3064XL-7CS48I

IC ISP CPLD 64 MCELL 3.3V 48-CSP
Data Sheet
0-416: $4.95
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
XCR3032
XCR3032
Other

Data Sheet
Negotiable
XCR3032A: 32
XCR3032A: 32
Other

Data Sheet
Negotiable
XCR3032C
XCR3032C
Other

Data Sheet
Negotiable
XCR3032XL
XCR3032XL
Other

Data Sheet
Negotiable
XCR3032XL 32
XCR3032XL 32
Other

Data Sheet
Negotiable
XCR3032XL-10CS48I
XCR3032XL-10CS48I

IC CPLD 3.3V ZERO PWR 48-CSP
Data Sheet
0-416: $1.98
